LINCOLN VANTAGE 580

Features

• Compact case with stainless steel enclosure
• Multi-process welding, separate arc gouge mode
• Plenty of ac generator power industrial diesel engine, 4 cylinder 1800 rpm turbo-charged Perkins® innovative service accessPowerful 580Amp turbo charged diesel engine driven welder
• 500Amps @ 100% duty cycle
• Constant current/constant voltage
• Multi process welder capable of MMA (Stick), MIG, FCAW, TIG & carbon arc gouging
• Fitted with Voltage Reduction Device (VRD)
• Digital volt/amp meters
• 4 cylinder water cooled Perkins diesel engine
• Auxiliary power 20kW - 2 x 240v/15Amp & 1 x 415v/32Amp outlet
• Three year warranty on parts and labour

• Suitable for MMAW, MIG, FCAW and Touch-Start™ TIG welding applications
• Ideal for on-site welding applications and use of auxilliary power for operating power tools, lighting or emergency power back up
• Suitable for contractors, mobile service/maintenance and mine site applications

Technical Specifications
Type Engine Drive Welder
Power Rating 22 kW
Voltage Rating 415/240 V
Current Rating 30-580A
Weight 586kg
Size 913mm x 687mm x 1590mm
Maximum TIG Rod Size 4.0mm
Machine Class Diesel
Maximum Electrode Size 6.0mm
Machine Series Vantage®
Duty Cycle 500A, 40V @ 100%
525A, 39V @ 60%
20-250A DC TIG
Welding Process Stick, TIG, MIG, Flux-Cored, Gouging
Horsepower & Displacement 43HP @ 1850RPM

Engine Type Perkins® 404D-22 Turbo
4 cylinder
Diesel, Turbo
